The photoelectric switch JL-214/224 series is applicable to control the street lighting, garden lighting, passage lighting and doorway lighting automatically in accordance with the ambient natural lighting level.
Feature
1. 5-30s time delay.
2. Surge Arrester (MOV) Optional Design.
3. JL-214B/224B has an omni-directional face top sensor for customer applications per BS5972-1980
4. 3 pin twist lock plug meets the ANSI C136.10, CE,ROHS.
| Product Model |
JL-214A/JL-224A |
JL-214A/JL-224B |
JL-214C/JL-224C |
| Rated Voltage |
110-120VAC |
220-240VAC |
110-277VAC |
| Applicable Voltage Range |
100-140VAC |
200-260VAC |
105-305VAC |
| Rated Frequency |
50/60Hz |
||
| Rated Loading |
1000W Tungsten, 1800VA Ballast |
||
| Power Consumption |
1.5VA |
||
| On/Off Level |
6Lx on |
||
| Ambient Temperature |
-40℃-+70℃ |
||
| Related Humidity |
0.99 |
||
| Overall Size |
84(Dia)*66mm |
||
| Weight Approx |
80grs |
||
