The photocontroller JL-24 series is applicable to control the street lighting, garden lighting, passage lighting and doorway lighting automatically in accordance with the ambient natural lighting level.
Feature
1. ANSI C136.10-1996 Twist Lock
2. Applicable Voltage Range: 90-305VAC
3. Time Delay of 10 seconds
4. Surge Arrester Built-In
5. Fail-On Mode
6. Dimming Output: 0-10V
|
Product Model |
JL-241C |
|
Rated Voltage |
110-277VAC |
|
Applicable Voltage Range |
90-305VAC |
|
Rated Frequency |
50/60Hz |
|
Rated Loading |
1000W Tungsten, 1800VA Ballast, 5A e-Ballast |
|
Power Consumption |
1.2W Average |
|
On/Off Level |
50 Lx |
|
Time Delay |
10 seconds |
|
Surge Protection |
640 Jolue/4000 Amp |
|
Ambient Temp. |
-40℃ ~ +70℃ |
|
Related Humidity |
99% |
|
Overall Size |
84(Dia.) x 66mm |
|
Weight Approx. |
200 grs |
|
IP Protection |
IP65 |
